EVC 250/350 Continuous Motion Series

The new EVC 250/350 Continuous Motion series are high performance modular continuous motion vertical form fill and seal machines for traditional and fragile products.

Continuous motion describes a mechanism that is moving continuously without pausing. The superiority of the continuous sealing system is that it enables the achievement of 100% hermetic seals at high speeds.

Our machine was tested at a high speed of 200 mechanical cycles per minute. In particular, it reduces the possibility of contaminants getting into the seal, which prevents effective sealing and is not cosmetically acceptable for the end-user/shopper.

It prevents proper sealing of the film, resulting in expensive machine downtime and scrap product, which can occur on standard intermittent machines.

Main Features

Various Types of Bags, pillow, gusset, block bottom, string bags etc.
Continuous Vertical and Horizontal Sealing ensure 100% non-leakage and smooth sealing
Adaptable for various types of filling Systems Multi-head Weigher, Linear Weigher, Volumetric Dosing, Auger Filler, Piston filler, etc.
Parts that are in contact with product produced from AISI 304 stainless steel
Adaptable for different sealing systems such as; impulse sealing, carrier handle bag, easy-open bag, euro-slot bag, round hole bag, string bags, straight cut, tear notch cut, and zig-zag cut bags (OPTIONAL)
Wrapping materials; Polypropylene, laminates and coupled materials in general, barrier film, water-soluble film, biaxially oriented films, and other heat sealing materials such as polyethylene

Technical Specifications

Dimensions	CH250	CH350
Width	1485 mm	1585 mm
Length	2210 mm	2210 mm
Height	1890 mm	2075 mm
Weight	1200 kg	1350 mm
Mechanical Speed (Bag/min)	200	180
Operational Speed (Bag/min)	130	110
Bag length (Min. – Max.)	40 - ... mm	40 - ... mm
Bag width (Min. – Max.)	30-240 mm	30 - 340 mm
Reel Outer diameter	400 mm	400 mm
Reel Width	700 mm	900 mm
Power Requirement	8 KW	9 KW
Voltage requirement	380V 3 Phase 50Hz	380V 3 Phase 50Hz
Air Requirement	150 lt/min.	150 lt/min.
Air pressure (Min.)	6 Bar	6 Bar

Get in touch

Need assistance? We're here to help and answer any questions you might have.

Package Types

Bag Type PP

Bag Type GB

Bag Type GB-AB

Bag Type GBI

Bag Type GBMI

Bag Type GBM

Bag Type GBC
