Main Features
- Parts that are in contact with product produced from AISI 304 stainless steel
- Various Types of Bags, pillow, gusset, block bottom, string bags etc.
- Adaptable for various types of filling Systems Multi-head Weigher, Linear Weigher, Volumetric Dosing, Auger Filler, Piston filler, etc.
- Adaptable for different sealing systems such as; impulse sealing, carrier handle bag, easy-open bag, euro-slot bag, round hole bag, string bags, straight cut, tear notch cut, and zig-zag cut (OPTIONAL)
- Wrapping materials; Polypropylene, laminates and coupled materials in general, barrier film, water-soluble film, biaxially oriented films, and other heat sealing materials such as polyethylene
Technical Specifications
| Dimensions | IM250 | IM350 |
| Width | 1485 mm | 1585 mm |
| Length | 2056 mm | 2056 mm |
| Height | 1710 mm | 2075 mm |
| Weight | 1200 kg |
1350 mm |
| Mechanical Speed (Bag/min) | 100 | 90 |
| Operational Speed (Bag/min) | 70 | 60 |
| Bag length (Min. – Max.) | 40 - 360 mm | 40 - 500 mm |
| Bag width (Min. – Max.) | 30-240 mm | 30 - 340 mm |
| Reel Outer diameter | 400 mm | 400 mm |
| Reel Width | 700 mm | 900 mm |
| Power Requirement | 5 KW | 6 KW |
| Voltage requirement | 380V 3 Phase 50Hz | 380V 3 Phase 50Hz |
| Air Requirement | 150 lt/min. | 150 lt/min. |
| Air pressure (Min.) | 6 Bar | 6 Bar |
Package Types
Bag Type GBI
Bag Type PP
Bag Type GB
Bag Type GB-AB
Bag Type GBMI
Bag Type GBM
Bag Type GBC
