Main Features
- Conveyor can operate in both directions
- It is speed controlled and the belt working speed can be adjusted
- Automatic product counting and limit setting system
Technical Specifications
- Min. Length=6500mm
- Max.Length=17000 mm
- Consists of 4 booms, 1 fixed + 3 moving
- Final boom can be raised up to max.3.5 meters with hydraulic piston
- 2.6 mm thick flat PVC belt with mechanical connection
- The main traction cylinder is polyurethane coated and conical
- Back and forth movements of the telescopic conveyor booms controlled by inductive sensors
- Two different control units are located on the front and on the main control panel
- Machine chassis is painted with electrostatic powder paint
- Main frame 6 mm, first telescope 5 mm, second telescope 4 mm, third telescope 3 mm (St37 quality)
- Maximum 50kg/meter carrying capacity
- Conveyor can operate in both directions
- It is speed controlled and the belts working speed can be adjusted
- Conveyor elongation and shortening are driven by a chain-gear drive
- Automatic product counting and limit setting system
- All electronic parts are Schneider brand
Areas of Use
Warehouses
Logistics companies
Cargo companies
Moving companies
